Mô tả
| Basic Information | ||
| Supported CPU | Supports 10th Gen Intel Core Processors, Pentium Gold and Celeron Processors Processor socket LGA1200 | |
| Chipset | Intel H510 Chipset | |
| Form Factor | m-ATX Form Factor 9.3 in. x 7.95 in. (23.6 cm x 20.2 cm) | |
| Audio | Realtek ALC897/ ALC892 Codec 7.1-Channel High Definition Audio | |
| Expansion Slots | ||
| PCI | 1x PCIe 3.0 x16 slot (From CPU) 1x PCIe 3.0 x1 slot (From PCH) | |
| M.2 Socket | 1x M.2 slot (Key M, from H510 chipset) | |
| Memory | ||
| Type | DDR4 | |
| Slots | 2x DDR4 memory slots | |
| Supported Memory | Supports 1R 2133/ 2666/ 2933 MHz for 10th Gen Intel CPU (by JEDEC & POR) Supports Dual-Channel mode Supports non-ECC, un-buffered memory Supports Intel Extreme Memory Profile (XMP) | |
| Maximum Memory | Up to 64GB | |
| Graphics | ||
| Graphics | 1x VGA port, supports a maximum resolution of 2048×1536 60Hz, 1920×1200 60Hz 1x HDMI 1.4 port, supports a maximum resolution of 4K 30Hz | |
| Connector & Ports | ||
| HDMI | 1x HDMI 1.4 port | |
| VGA (s) | 1x VGA port | |
| USB (s) | Intel H510 Chipset 4x USB 3.2 Gen 1 5Gbps ports (2 Type-A ports on the back panel, 2 ports available through the internal USB connector) 6x USB 2.0 ports (4 Type-A ports on the back panel, 2 ports available through the internal USB 2.0 connector) | |
| LAN Port (s) | 1x Realtek RTL8111 Gigabit LAN controller | |
| Supported Storage | 4x SATA 6Gb/s ports (From H510 Chipset) 1x M.2 slot (Key M, from H510 chipset) Supports up to PCIe 3.0 x4 Supports SATA 6Gb/s Supports 2242/ 2260/ 2280 storage devices | |
| Audio | 1x Front panel audio connector | |
| Internal I/O Ports | 1x 24-pin ATX main power connector 1x 8-pin ATX 12V power connector 4x SATA 6Gb/s connectors 1x USB 2.0 connector (support additional 2 USB ports) 1x USB 3.2 Gen 1 5Gbps connector (support additional 2 USB ports) 1x 4-pin CPU fan connector 1x 4-pin system fan connector 1x Front panel audio connector 2x System panel connectors 1x Serial port connector 1x TPM module connector 1x Chassis Intrusion connector 1x Clear CMOS jumper | |
| TPM (Trusted Platform Module ) | 1 x TPM module connector | |
| Warranty Information | ||
| Manufacturing Warranty | 03 Years | |
